Specially designed for easy installation, Eaton's BR load centers house the branch circuit breakers and the wiring required to distribute power to individual circuits. The panels serve as the main breaker for service entrances. The main breaker protects the main entire panel and can be used as a service disconnect. The branch breakers protect the wires leading to individual electrical loads such as fixtures and outlets. The BR816B200RF is a 200 amp outdoor main breaker with 8 spaces and 16 circuits.
- 200 amp main breaker load center
- Tangential center knockout easier installation for conduit applications
- Bonding Z-strap provides easy field conversion for service entrance applications
- Twin neutral bars minimum 150% neutral capacity
- Surface Mount
- Uses type BR, BD, BQ, GFCB Eaton circuit breakers
- Depth: 5.19 in.
- UL Listed: Yes
- Breakers Included: Yes
- Circuit Protection Type: Main Breaker
- Height: 25 in.
- Width: 14.31 in.
- Indoor or Outdoor: Outdoor
