Raise the bar on lightweight durability with our JLA Compact Lever Hoist. Available in 3/4-ton, 1-1/2–ton, and 3-ton models, this hoist delivers industry-leading size, weight, and durability. Safety is also at the forefront, backed by an auto-engage clutch that allows for easy load chain adjustment while protecting against accidental freewheeling under load. Perfect for your normal, everyday applications, the JLA series also expands your capabilities with its compact body small enough to fit in your lunchbox, allowing you to get into tight areas where larger body hoists cannot. All of this, plus a JET Assurance Lifetime Guarantee.
- Compact and lighter than any lever hoist on the market
- Features the shortest handle on the market for getting into tight areas
- Fused brake reduces maintenance and carries a lifetime warranty
- Weston-style double pawl system provides added safety
- Grade 100 load chain is a smaller, more compact link with improved working load limits and is zinc plated for maximum corrosion protection
- Cast-steel safety latches will not bend out of shape like stamped steel latches
- Anodized surfaces for unmatched corrosion protection
- This product complies with ANSI / ASME B30.21 and HAST-3 standards
- Shipyard hooks available on 1.5-ton and 3-ton models
Specifications:
- Headroom (in.) 10.24
- Capacity (Lbs.) 1650
- Lift (Ft.) 20
- Load Capacity (Tons) 3/4
- Load Chain Dimensions dia/mm) 5 x 15
- Weight (Lbs.) 13.54
- Lever Length (in.) 7.09
- Lbs. of Pull to Lift Capacity 65
- Ship Yard Hooks NO
